Smart Solar. Stable Power.
Smart Solar. Stable Power.
All-in-one solar street lighting for roads, communities, parking areas, and infrastructure projects.
The Arden Series is a project-grade all-in-one solar LED street light designed for reliable outdoor lighting where grid connection is costly, unstable, or unavailable. It integrates a high-efficiency LED module, monocrystalline solar panel, LiFePO₄ battery, and intelligent controller into one compact system for faster installation and lower maintenance.
Built for practical project use, the Arden Series can be selected according to installation height, lighting requirement, project location, and local sunlight conditions.
Send us your project location, pole height, road width, quantity, and required lighting hours. Our team will recommend a suitable configuration.
Arden Series is designed for projects that require fast deployment, stable lighting performance, and lower long-term operating cost. Compared with conventional grid street lights, it does not require trenching, cabling, or electricity connection.
No trenching, underground cabling, or grid connection required for installation.
Integrated design helps reduce project installation complexity and labor time.
Powered by solar energy, suitable for areas where electricity cost is high.
Multiple configurations available for roads, communities, industrial parks, and municipal projects.
Select the recommended model based on project road type, installation height, lighting requirement, and local sunlight condition.
| Project Requirement | Recommended Model | Power | Suggested Mounting Height |
|---|---|---|---|
| Community roads, pathways, small parking areas | TH-AIOLS-1014 | 90W | 6–7m |
| Village roads, residential streets, internal roads | TH-AIOLS-1015 | 120W | 7–8m |
| Wider roads, industrial parks, project roads | TH-AIOLS-1016 | 150W | 8–10m |
Final selection should be based on project location, road width, pole distance, sunlight condition, required lighting mode, and local lighting standard.
Comprehensive technical parameters for project planning and configuration.
3 Modules · 90W · 6–7m Mounting Height
4 Modules · 120W · 7–8m Mounting Height
5 Modules · 150W · 8–10m Mounting Height
| Specification | TH-AIOLS-1014 | TH-AIOLS-1015 | TH-AIOLS-1016 |
|---|---|---|---|
| Power Options | 90W | 120W | 150W |
| Battery Capacity | 3.2V / 52Ah | 3.2V / 65Ah | 3.2V / 90Ah |
| Solar Panel | 6V / 75W | 6V / 90W | 6V / 110W |
| Solar Panel Efficiency | >21% | >21% | >21% |
| LED Type & Quantity | 3030 / 135PCS × 1W | 3030 / 180PCS × 1W | 3030 / 225PCS × 1W |
| Luminous Efficiency | 180 lm/W | 180 lm/W | 180 lm/W |
| Dimension | 887 × 400 × 65mm | 1159 × 400 × 65mm | 1436 × 400 × 65mm |
| Waterproof Rating | IP66 | IP66 | IP66 |
| Lighting Duration | 24–36 hrs | 24–36 hrs | 24–36 hrs |
| Color Temperature | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K |
| Battery Type | LiFePO₄ | LiFePO₄ | LiFePO₄ |
| Solar Panel Type | Monocrystalline | Monocrystalline | Monocrystalline |
| Housing Material | Die-cast Aluminum with Galvanized Sheet | Die-cast Aluminum with Galvanized Sheet | Die-cast Aluminum with Galvanized Sheet |
| Control Mode | Sensor + Remote + Timing | Sensor + Remote + Timing | Sensor + Remote + Timing |
| Working Temperature | -20°C to +60°C | -20°C to +60°C | -20°C to +60°C |
Engineered for reliability, efficiency, and long-term cost savings in demanding outdoor environments.
180 lm/W efficiency with precision optical lens design for road illumination.
Stable battery performance with BMS protection for outdoor solar lighting use.
High-efficiency solar charging system designed for daily outdoor operation.
Dust and water protection for long-term use in outdoor environments.
Premium components designed for durability, efficiency, and easy installation.
Versatile solar lighting solutions for diverse infrastructure requirements.
Suitable for urban roads, village roads, secondary roads, and internal roadways.
Practical for community streets, pathways, and neighborhood access roads.
Suitable for factory parks, warehouse zones, and internal traffic roads.
Can be used for commercial, public, or community parking lots where trenching is not preferred.
Appropriate for local roads, community infrastructure, and public development areas.
A reliable option where grid connection is costly, unstable, or unavailable.
All-in-one structure helps reduce on-site installation complexity and project deployment time.
Confirm pole height, road width, pole distance, quantity, and required lighting hours.
Install the bracket and adjust the angle according to project installation needs.
Mount the solar street light on the pole without grid wiring or trenching.
Use remote control or preset timing mode according to project requirements.
Standard package components for project supply and installation.
Project documentation and certifications can be provided according to the confirmed model and order requirement.
Available certification support for international project requirements.
Material compliance support available according to order requirement.
Factory quality management system for stable production control.
Rigorous testing protocols before shipment for project supply.
Common questions for contractors, EPC companies, distributors, and project buyers.
Yes. The Arden Series includes battery storage, so it can continue operating when sunlight is reduced. Actual backup performance depends on the selected configuration, local weather conditions, and lighting mode.
No. The all-in-one design helps simplify installation. There is no trenching or grid wiring required, which can reduce installation time and labor complexity.
Selection depends on project location, pole height, road width, required brightness, and required lighting hours. Tedlighting can recommend the suitable Arden model based on your project details.
Yes. Project-based configuration can be supported for battery, panel, lighting mode, color temperature, and other practical requirements depending on quantity and project scope.
Yes. For project supply, Tedlighting can support technical discussion, configuration selection, and available documentation according to the final model and order requirement.
For EPC, contractor, distributor, and government project quotations, please provide project location, pole height, quantity, road width, and required lighting hours for accurate configuration and pricing.
