Modular LED Floodlight 200W → 1500W

Heavy-duty floodlights with field-swappable LED modules and driver bays. Same platform from 200W to 1500W — service the fixture without removing it from the pole.

Request Quote → Download Catalog

150 lm/W

Efficacy

100,000 hrs

L70 Lifespan

5 years

Warranty

20 kV

Surge Protection

Technical Specifications

Comprehensive technical parameters for project planning and configuration.

Specification	Modular Flood 200W 200W	Modular Flood 300W 300W	Modular Flood 500W 500W	Modular Flood 750W 750W	Modular Flood 1000W 1000W	Modular Flood 1500W 1500W
Power	200W	300W	500W	750W	1000W	1500W
Luminous Flux	30,000 lm	45,000 lm	75,000 lm	112,500 lm	150,000 lm	225,000 lm
Efficacy	150 lm/W	150 lm/W	150 lm/W	150 lm/W	150 lm/W	150 lm/W
Beam Angle	30° / 60° / 90°	30° / 60° / 90°	15° / 30° / 60°	15° / 30° / 60°	10° / 25° / 45°	10° / 25° / 45°
Weight	6.8 kg	9.4 kg	14.2 kg	20.5 kg	26.8 kg	39.4 kg
Dimensions	420 × 380 × 90 mm	490 × 440 × 100 mm	580 × 520 × 110 mm	680 × 600 × 120 mm	760 × 660 × 130 mm	880 × 760 × 140 mm
Application	Loading docks, mid-size yards, façades	Container yards, sports courts, parking	Stadium periphery, large yards, ports	Football pitches, container terminals	Stadiums, airports, mining headlamps	Mega-projects, broadcast-grade venues

Across Every Model

Modular engineering. Industrial output.

Field-Swap Modules

Replace LED bays in minutes

IP66 / IK10

Sealed against the worst weather

20kV Surge

Industrial-grade lightning protection

10° to 90° Optics

Spot to wide-area on the same body

Marine-Grade Body

Salt-spray tested aluminum housing

Quick-Lock Yoke

Pole-side aiming without tools

Where it's installed

Stadiums, ports, façades — one platform

From 200W façade washers to 1500W broadcast-grade stadium fixtures.

Container & Storage Yards

High-output flood beams from 500W to 1500W — uniform illumination across the largest open-air working surfaces.

Loading Docks & Logistics

Glare-free area lighting for 24/7 logistics operations, drive-through bays and cross-dock facilities.

Architectural Facades

Asymmetric and narrow-beam optics for façade washing, monument lighting and prestige architectural projects.

Why projects keep ordering

Three reasons engineers prefer the modular platform

Field-Swap Modules

Service the fixture without removing it

Each LED bay and driver compartment is independently replaceable in the field — no need to lower the floodlight or de-spec the project.

Modular LED bays unlock with quarter-turn fasteners
Independent driver compartment
Replacement parts in stock for 10 years

Built for Punishment

Marine-grade aluminum & sealed gasketing

Salt-spray tested 1,000+ hours, IK10 against vandalism and IP66 sealed against the worst weather a port or mine can throw at it.

Marine-grade aluminum housing
Salt-spray tested 1,000+ hours
20kV surge protection on every model

10° to 90°

From narrow spot to wide flood

The same housing accepts seven optical inserts — go from a 10° asymmetric spot to a 90° symmetric flood by swapping the lens, not the fixture.

7 beam options on the same body
Photometric (.IES) for every combination
Custom optics for tender projects

Dimensions

880 × 760 × 140 mm

Best for: Mega-projects, broadcast-grade venues

Shared Across The Series

Common Specifications

Shared technical parameters across every model in the series.

Input Voltage(V)	AC85-305V
Color	3000 / 4000 / 6000K
Body Finish	Grey
CRI	>70
PF	>0.95
SPF	4 / 6KV / 10KV
Lamp Body Material	Die-cast Aluminum + Anti-UV PC Lens
Lifespan	50,000 hours
IP Level	IP65
