Smart Solar. Stable Power.
Smart Solar. Stable Power.
A complete street-light series engineered for every road class — from quiet residential streets to major highway interchanges. One platform, six wattages, and the same industrial-grade build across the lineup.
Used in 160+ countries · Free IES & photometric layout
Efficacy
Lifespan
Warranty
Surge Protection
Comprehensive technical parameters for project planning and configuration.
|
Specification
|
TH-LS-1076
|
TH-LS-1077
|
TH-LS-1078
|
TH-LS-1079
|
|---|---|---|---|---|
| Lamp Power | 100W | 150W | 200W | 240W |
| Luminous Flux | 16000 lm | 24000 lm | 32,200 lm | 38,400 lm |
| Lamp Size (mm) | 495×236×40 | 495×263×40 | 560×236×40 | 635×294×40 |
| Beam Optics | II / III | II / III | II / III | II / III / V |
| Efficacy | 160-190 lm/W | 160-190 lm/W | 160-190 lm/W | 160-190 lm/W |
| Input Voltage | AC 100–277V, 50/60Hz | AC 100–277V, 50/60Hz | AC 100–277V, 50/60Hz | AC 100–277V, 50/60Hz |
| Color Temperature (CCT) | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K |
| CRI | >70 (Ra) | >70 (Ra) | >70 (Ra) | >70 (Ra) |
| Power Factor (PF) | >0.95 | >0.95 | >0.95 | >0.95 |
| Housing Material | Die-cast Aluminum + Anti-UV PC / Tempered Glass Lens | Die-cast Aluminum + Anti-UV PC / Tempered Glass Lens | Die-cast Aluminum + Anti-UV PC / Tempered Glass Lens | Die-cast Aluminum + Anti-UV PC / Tempered Glass Lens |
| Body Finish | Grey (RAL 7035) — custom on request | Grey (RAL 7035) — custom on request | Grey (RAL 7035) — custom on request | Grey (RAL 7035) — custom on request |
| IP / IK Rating | IP66 · IK10 | IP66 · IK10 | IP66 · IK10 | IP66 · IK10 |
| Surge Protection | 10kV standard / 20kV optional | 10kV standard / 20kV optional | 10kV standard / 20kV optional | 10kV standard / 20kV optional |
| Lifespan | 50,000+ hours (L70) | 50,000+ hours (L70) | 50,000+ hours (L70) | 50,000+ hours (L70) |
| Pole Mount | Ø60mm side-arm (Ø50–76mm adapters available) | Ø60mm side-arm (Ø50–76mm adapters available) | Ø60mm side-arm (Ø50–76mm adapters available) | Ø60mm side-arm (Ø50–76mm adapters available) |
| Smart Control | 0–10V / DALI / NEMA / Zhaga socket optional | 0–10V / DALI / NEMA / Zhaga socket optional | 0–10V / DALI / NEMA / Zhaga socket optional | 0–10V / DALI / NEMA / Zhaga socket optional |
| Warranty | 5 years standard | 5 years standard | 5 years standard | 5 years standard |
Project Resources
Everything tender engineers, EPCs and distributors need to specify, install and maintain the series.
Industry-leading 150 lm/W efficacy
Built for the harshest weather
10kV standard / 20kV optional
0-10V / DALI / NEMA / Zhaga
Corrosion-resistant body
Driver swap in under 60 seconds
One series scales across every road class — choose the wattage and optic, the platform stays the same.
Warm, glare-controlled illumination for neighborhoods, cul-de-sacs and pedestrian-friendly streets — Type II / III optics keep light on the road, not in bedroom windows.
Uniform brightness across multi-lane city streets, intersections and crosswalks — meeting CIE M1–M3 road-class targets with predictable photometric layouts.
High-mast and conventional pole installations for motorways, ramps and toll plazas where uptime, surge protection and serviceability are non-negotiable.
We don't compromise on the chip. Every model in the series uses genuine Philips LEDs binned for color consistency, paired with a constant-current Mean Well, Sosen or Inventronics driver.
Die-cast aluminum housing, tempered glass lens and a fully gasketed driver compartment. Tested at IEC labs to survive monsoons, sandstorms and decades of UV exposure.
Open the service hatch, unplug the driver, plug in the new one — close. No specialist tools, no rewiring, no truck back to the depot. Built around what tender engineers actually score.
Proven On The Ground
From municipal streets in Southeast Asia to national highways across Africa and the Gulf — our LED street lights ship to projects of every scale.
120W and 150W LED street lights deployed across 14 km of dual-carriageway coastal highway.
Long-span 200W highway lighting installation — IP66 rated for dust storms and heavy rain.
150W high-output LED street lights with 20kV surge protection for desert climate reliability.
Countries
Years Experience
Distribution Partners
Standard Warranty
Quality That Lasts
|
Specification
|
TedLighting
|
Low-Cost Street Light
|
|---|---|---|
|
LED Chips
|
Genuine Philips LEDs, binned for CCT consistency
|
Generic chips, mixed bins, color drift
|
|
Driver Brand
|
Mean Well / Sosen / Inventronics
|
Unbranded, short MTBF
|
|
Housing Material
|
Die-cast aluminum + tempered glass lens
|
Thin sheet metal or plastic body
|
|
IP Rating
|
IP66 — fully sealed, gasketed driver bay
|
IP54–IP65, leaks under monsoon
|
|
Impact Rating
|
IK10 — vandal-proof
|
Not rated
|
|
Surge Protection
|
10kV standard / 20kV optional
|
2–4kV or none
|
|
Heat Dissipation
|
Engineered fin design, thermal-tested
|
Flat back, runs hot, lifespan halved
|
|
Optics
|
Type II / III / V — project-tunable
|
Single fixed lens, wasted light
|
|
Warranty
|
5 years with regional spare-parts stock
|
1 year, no local support
|
|
Project Support
|
Photometric layout, on-site training, audits
|
Box-shipped, no engineering
|
|
IES Files
|
Calibrated .IES per model — free
|
Not provided or simulated
|
For Every Buyer
From single-pole replacements to nationwide highway tenders — we tailor pricing, branding and logistics to your role.
Fast quotes, in-stock SKUs, install-ready packaging and on-site technical support.
OEM / ODM branding, dealer pricing tiers and protected territories for serious partners.
Compliance documentation, factory audits and tender-grade certifications for public road projects.
Trusted Worldwide
From the SMT line to the container ship — every step is documented, tested and audit-ready.
ISO 9001 production lines with automated SMT, AOI inspection and 100% in-circuit testing.
Every fixture aged 4–12 hours under full load before packing — zero infant mortality on site.
IP66 chamber testing for every batch — high-pressure water jets from all angles.
Anti-shock foam, double-walled cartons and palletized loading for ocean freight.
On-site commissioning, photometric verification and operator training in 160+ countries.
Tender-ready CE, RoHS, IEC, TÜV, ENEC, SAA, BIS reports — issued on demand.
Project Inquiry
Share your road class, mounting height, pole spacing and target lux — our lighting engineers will return a complete photometric layout, BOQ and quotation within 24 hours.
Response within 24 hours on business days
Free photometric layout (.IES) for qualified projects
Send your road details → Get photometric layout + quotation in 24 hours
Explore More
Send us your road class, mounting height and target lux — our engineers will return a photometric layout and quote within 24 hours.
