A complete street-light series engineered for every road class — from quiet residential streets to major highway interchanges. One platform, six wattages, and the same industrial-grade build across the lineup.
Used in 160+ countries · Free IES & photometric layout
Efficacy
Lifespan
Warranty
Surge Protection
Shared technical parameters across every model in the series.
| Input Voltage(V) | AC85-305V |
| Color | 3000 / 4000 / 6000K |
| Body Finish | Grey |
| CRI | >70 |
| PF | >0.95 |
| SPF | 4 / 6KV / 10KV |
| Lamp Body Material | Die-cast Aluminum + Anti-UV PC Lens |
| Lifespan | 50,000 hours |
| IP Level | IP65 |
Comprehensive technical parameters for project planning and configuration.
|
Specification
|
TH-LS-1076
|
TH-LS-1077
|
TH-LS-1078
|
|---|---|---|---|
| Lamp Power | 50W | 100W | 150W |
| Luminous Flux | 16000 lm | 24000 lm | 32,200 lm |
| Lamp Size (mm) | 495×236×40 | 495×263×40 | 560×236×40 |
| Beam Optics | II / III | II / III | II / III |
| Efficacy | 160-190 lm/W | 160-190 lm/W | 160-190 lm/W |
| Input Voltage | AC 100–277V, 50/60Hz | AC 100–277V, 50/60Hz | AC 100–277V, 50/60Hz |
| Color Temperature (CCT) | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K | 3000K / 4000K / 6000K |
| CRI | >70 (Ra) | >70 (Ra) | >70 (Ra) |
| Power Factor (PF) | >0.95 | >0.95 | >0.95 |
| Housing Material | Die-cast Aluminum + Anti-UV PC / Tempered Glass Lens | Die-cast Aluminum + Anti-UV PC / Tempered Glass Lens | Die-cast Aluminum + Anti-UV PC / Tempered Glass Lens |
| Body Finish | Grey (RAL 7035) — custom on request | Grey (RAL 7035) — custom on request | Grey (RAL 7035) — custom on request |
| IP / IK Rating | IP66 · IK10 | IP66 · IK10 | IP66 · IK10 |
| Surge Protection | 10kV standard / 20kV optional | 10kV standard / 20kV optional | 10kV standard / 20kV optional |
| Lifespan | 50,000+ hours (L70) | 50,000+ hours (L70) | 50,000+ hours (L70) |
| Pole Mount | Ø60mm side-arm (Ø50–76mm adapters available) | Ø60mm side-arm (Ø50–76mm adapters available) | Ø60mm side-arm (Ø50–76mm adapters available) |
| Smart Control | 0–10V / DALI / NEMA / Zhaga socket optional | 0–10V / DALI / NEMA / Zhaga socket optional | 0–10V / DALI / NEMA / Zhaga socket optional |
| Warranty | 5 years standard | 5 years standard | 5 years standard |
Project Resources
Everything tender engineers, EPCs and distributors need to specify, install and maintain the series.
Industry-leading 150 lm/W efficacy
Built for the harshest weather
10kV standard / 20kV optional
0-10V / DALI / NEMA / Zhaga
Corrosion-resistant body
Driver swap in under 60 seconds
We don't compromise on the chip. Every model in the series uses genuine Philips LEDs binned for color consistency, paired with a constant-current Mean Well, Sosen or Inventronics driver.
Die-cast aluminum housing, tempered glass lens and a fully gasketed driver compartment. Tested at IEC labs to survive monsoons, sandstorms and decades of UV exposure.
Open the service hatch, unplug the driver, plug in the new one — close. No specialist tools, no rewiring, no truck back to the depot. Built around what tender engineers actually score.
Quality That Lasts
|
Specification
|
TedLighting
|
Low-Cost Street Light
|
|---|---|---|
|
LED Chips
|
Genuine Philips LEDs, binned for CCT consistency
|
Generic chips, mixed bins, color drift
|
|
Driver Brand
|
Mean Well / Sosen / Inventronics
|
Unbranded, short MTBF
|
|
Housing Material
|
Die-cast aluminum + tempered glass lens
|
Thin sheet metal or plastic body
|
|
IP Rating
|
IP66 — fully sealed, gasketed driver bay
|
IP54–IP65, leaks under monsoon
|
|
Impact Rating
|
IK10 — vandal-proof
|
Not rated
|
|
Surge Protection
|
10kV standard / 20kV optional
|
2–4kV or none
|
|
Heat Dissipation
|
Engineered fin design, thermal-tested
|
Flat back, runs hot, lifespan halved
|
|
Optics
|
Type II / III / V — project-tunable
|
Single fixed lens, wasted light
|
|
Warranty
|
5 years with regional spare-parts stock
|
1 year, no local support
|
|
Project Support
|
Photometric layout, on-site training, audits
|
Box-shipped, no engineering
|
|
IES Files
|
Calibrated .IES per model — free
|
Not provided or simulated
|
For Every Buyer
From single-pole replacements to nationwide highway tenders — we tailor pricing, branding and logistics to your role.
Fast quotes, in-stock SKUs, install-ready packaging and on-site technical support.
OEM / ODM branding, dealer pricing tiers and protected territories for serious partners.
Compliance documentation, factory audits and tender-grade certifications for public road projects.
One series scales across every road class — choose the wattage and optic, the platform stays the same.
Warm, glare-controlled illumination for neighborhoods, cul-de-sacs and pedestrian-friendly streets — Type II / III optics keep light on the road, not in bedroom windows.
Uniform brightness across multi-lane city streets, intersections and crosswalks — meeting CIE M1–M3 road-class targets with predictable photometric layouts.
High-mast and conventional pole installations for motorways, ramps and toll plazas where uptime, surge protection and serviceability are non-negotiable.
Countries
Years Experience
Distribution Partners
Standard Warranty
Proven On The Ground
From municipal streets in Southeast Asia to national highways across Africa and the Gulf — our LED street lights ship to projects of every scale.
120W and 150W LED street lights deployed across 14 km of dual-carriageway coastal highway.
Long-span 200W highway lighting installation — IP66 rated for dust storms and heavy rain.
150W high-output LED street lights with 20kV surge protection for desert climate reliability.
Trusted Worldwide
From the SMT line to the container ship — every step is documented, tested and audit-ready.
ISO 9001 production lines with automated SMT, AOI inspection and 100% in-circuit testing.
Every fixture aged 4–12 hours under full load before packing — zero infant mortality on site.
IP66 chamber testing for every batch — high-pressure water jets from all angles.
Anti-shock foam, double-walled cartons and palletized loading for ocean freight.
On-site commissioning, photometric verification and operator training in 160+ countries.
Tender-ready CE, RoHS, IEC, TÜV, ENEC, SAA, BIS reports — issued on demand.
Project Inquiry
Share your road class, mounting height, pole spacing and target lux — our lighting engineers will return a complete photometric layout, BOQ and quotation within 24 hours.
Response within 24 hours on business days
Free photometric layout (.IES) for qualified projects
Send your road details → Get photometric layout + quotation in 24 hours
